Oscillating Tangential Knife CNC Router Combo with CCD for Sale

Vibrating Knife CCD CNC Router Combo in Action

Application of Oscillating Tangential Knife CNC Router Combo

Applicable Field

KR1325 is a good fit for the fabrication field, such as home textiles, automotive interiors (i.e., car foot pads), signage, packaging, composite materials, sealing materials, clothing, expanded polyethylene foam, and more.

Applicable Materials

Fabric, leather, synthetic leather, cardboard, KT board, PVC, PU, fiberglass, EVA, rubber, TPU, insole, wood, and more.

Distinctive Design of the Tangential Knife CNC Router

The design highlight of this model is that it integrates a milling cutter, a tangential oscillating cutting knife, and a CCD camera. Two-in-one design, you buy one machine, and you can actually use it as two machines. It is also a good solution for users with some space constraints.

CNC Knife Cutter Router Specification

• One motion head with a tangential oscillating knife and mill spindle. The two can be activated arbitrarily by compressed air according to production needs.

• This is the oscillating knife cutter for the combo machine.

• The vibrating knife cuts the materials with carbide knife blades.

• The vibrating knife CCD cnc router combo machine is equipped with a water-cooled milling spindle.

• The numerical control system adopts the particular XDW controller for cnc knife cutter router combo machine; it comes with a manual pulse generator (handwheel).

• There are two language options for the operating program: English and Chinese. Before delivery, we will switch the working language to English uniformly, so there will be no issues with the operation language once you receive the machine.

• The oscillating knife cnc router is equipped with an individual control box with a majority of electronic components inside.

• All the control buttons and switches on the control cabinet are labeled in English.

Quick Details of the CNC Router with Tangential Knife

• One tangential knife cutter

• One mill cutter

• With a CCD camera

• 1300x2500mm working area

• 3.0Kw spindle motor

• Stepper on X/Y/Z

• XDW cnc control system with hand wheel

• Operation language in English

Technical Data of Tangential Oscillating Knife CNC Router for Sale

FAQs about the CNC Router with Oscillating Knife Attachment

Q: Can I Cut the Fiberglass Cloth and Bagging Materials with This Machine?

A: Yes, of course. Since this machine is equipped with an oscillating tangential knife, you can use it to cut fiberglass cloth and packaging materials.

Q: Please Specify Which Table Type Is Best Suited to Foam Vs. Cardboard/Other Materials.

A: Given the requirements of spindle milling operations, the vacuum table for the machine must be made of rigid PVC.

Q: Whether The Standard Oscillating Knife Can Cleanly Cut Through 50–60mm EVA Foam In A Single Pass, Or If Multiple Passes/Pre-Scoring Is Required.

A: Yes, the standard knife can clearly cut through 50-60mm EVA foam in a single-pass.

Q: Whether The CCD Camera Option Is Worth Adding For Our Use Case, And The Price Difference With/Without It

A: If your application requires contour cutting along pattern edges or lines, choosing the CCD system is an excellent option; otherwise, it's not necessary.

Q: Do You Have Other Options On The Working Size?

A: Yes, we do. We have standard options like 1500x3000mm and 2000x4000mm. Also, we can make to order.

Q: Full Landed Cost To Melbourne, Australia (VIC 3000), Including Freight, And Confirmation Of Who Handles Australian Import Duty/GST — Is This DDP (Delivered Duty Paid) Or Do We Handle Customs Clearance Ourselves?

A: If we conclude the transaction on DDP terms, we will handle Australian import duty/GST and you don't need to handle customs clearance yourself.

Q: Lead Time From Deposit To Delivery

A: It would range from 20 to 30 days.

Q: Warranty Terms And How Spare Parts/Support Are Handled For Australian Customers.

A: Warranty is 12 months. We provide deliveries for any damaged parts caused by production or quality defects during the guarantee. You do not need to ship the defective parts back to our plant in Jinan, as it is not practical to do so.

Q: Power Requirements — Please Confirm Compatibility With Australian 230V/240V Single-Phase Power, Or If A Transformer/Electrician Work Is Required

A: The 3-phase power is great. Just a heads up:  Since our machine has two vacuum pumps, it uses more current when running on single-phase power. To ensure optimal performance, we suggest avoiding this mode of operation.

Q: What Is the Working Rate of This CNC?

A: It is 5000mm/min on average.

Q: Does A Set Of Oscillating Knife Blades Include In The Standard Package?

A: Yes, it does. One case of carbide blades would be shipped along with the machine to you for sample-making purposes.

If you like the tangential knife cnc router combo for sale here, please ask for a free proposal now.
